The patented conic system fits onto all ISO 50mm diameter tow balls. Easy to use and secure.
The system can be locked using the locking knob.
The special Buzz wrench is included for the installation of the product on the tow ball
The bike frame holders have soft rubber type straps to secure bikes.
They are quick and easy to use. They have been 100% tested in our production line.
You can safely tilt down the carrier far enough for gate access even with bikes on.
The tilting is released using a knob.
The product is supplied with an additional safety strap that allows to secure the bike.
The bike holder arms can be folded for storage, or when the vehicle is parked up.
Max number of bikes: 4
Fits bolt on tow ball: yes
Fits swan neck / detachable tow ball: yes
Max load capacity: 60kg
Max weight per bike: 15kg
Integrated lighting board: optional
Lighting board plug type: –
Bike carrier to tow ball lock: yes
Bike carrier to bike lock: no
The maximum permitted load you can carry is also determined by the tow bar nose weight; you will need to check you don’t exceed this before using any tow ball mounted bike carrier.
Requires 65mm clearance from center of tow ball to rear of vehicle.
