Engineered to defy gravity and elevate your performance, the Addict RC is our lightest production race bike ever. Whether you're attacking steep climbs or sprinting for the finish line, every aspect of this bike was meticulously crafted with one thing in mind – leaving everyone else in the dust.

Key features

• Addict RC HMX Carbon frame
• SRAM RIVAL 24 Speed drivetrain
• SRAM RIVAL brakes
• Syncros Capital 1.0 40 Disc wheelset
• Continental Grand Prix TR tires, 30x622
• Syncros Carbon & Alloy components
• Syncros handlebar tool

Technical Specifications

Frame	Addict RC HMX, race geometry, replaceable derailleur hanger, internal cable routing
Fork	Addict RC HMX Flatmount Disc, 27.2mm eccentric carbon steerer
Headset	Acros AIF-1317
Rear Derailleur	SRAM RIVAL eTap AXS, 24 Speed, Electronic Shift System
Front Derailleur	SRAM RIVAL eTap AXS Electronic Shift System
Shifters	SRAM RIVAL AXS HRD Shift-Brake System
Brakes	SRAM RIVAL AXS HRD Shift-Brake System
Crankset	SRAM RIVAL Crankset, 48-35T, Powermeter
Front Disc Rotor	SRAM Paceline CL, 160mm
Rear Disc Rotor	SRAM Paceline CL, 140mm
BB-Set	SRAM DUB PF ROAD 86.5
Handlebar	Syncros HB-R100-CF
H'stem	Syncros ST-R100-AL
Seatpost	Syncros SP-R101-CF
Seat	Syncros Belcarra V 2.0 Cut-out, CrMo rails
Chain	SRAM RIVAL
Wheelset	Syncros Capital 1.0 40 Disc, 24 Front, 24 Rear, Syncros Axle
Cassette	SRAM RIVAL XG1250, 10-36T
Extras	Syncros handlebar tool, SRAM AXS powerpack
Approx weight in KG	7.6
Approx weight in LBS	16.76
Grips	Syncros RC Bartape
Front Tire	Continental Grand Prix TR 30x622
Rear Tire	Continental Grand Prix TR 30x622
Max. System Weight	120kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.



Geometry

	XXS_47	XS_49	S_52	M_54	L_56	XL_58	XXL_61
A head tube angle	71.3 mm	71.8 mm	72.3 mm	72.8 mm	73.4 mm	73.6 mm	73.8 mm
B head tube length	90.0 mm	100.0 mm	113.0 mm	130.0 mm	150.0 mm	170.0 mm	190.0 mm
C top tube horizontal	519.0 mm	528.0 mm	542.0 mm	555.0 mm	572.0 mm	586.0 mm	602.0 mm
D standover height	725.0 mm	740.0 mm	758.0 mm	778.0 mm	799.0 mm	820.0 mm	840.0 mm
E BB offset	-74.0 mm	-74.0 mm	-73.0 mm	-72.0 mm	-72.0 mm	-72.0 mm	-72.0 mm
F BB height	270.5 mm	270.5 mm	271.5 mm	272.5 mm	272.5 mm	272.5 mm	272.5 mm
G wheel base	977.0 mm	983.2 mm	988.8 mm	990.8 mm	999.0 mm	1006.4 mm	1015.4 mm
H BB center to toptube center	412.5 mm	432.5 mm	452.1 mm	472.0 mm	492.2 mm	512.3 mm	532.4 mm
I BB center to top of seattube	422.5 mm	442.5 mm	462.1 mm	482.0 mm	502.2 mm	522.3 mm	542.4 mm
J seat angle	74.5 mm	74.5 mm	74.0 mm	73.6 mm	73.3 mm	72.8 mm	72.5 mm
K chainstay	410.0 mm	410.0 mm	410.0 mm	410.0 mm	410.0 mm	410.0 mm	410.0 mm
L reach	379.4 mm	386.3 mm	391.6 mm	395.2 mm	402.6 mm	406.1 mm	411.3 mm
M stack	501.3 mm	512.5 mm	525.5 mm	543.3 mm	564.5 mm	584.3 mm	604.2 mm
N stem length	80.0 mm	90.0 mm	100.0 mm	110.0 mm	110.0 mm	120.0 mm	120.0 mm
O handlebar width	360.0 mm	380.0 mm	380.0 mm	400.0 mm	400.0 mm	400.0 mm	420.0 mm
P cockpit reach	530.0 mm	547.0 mm	563.0 mm	577.0 mm	585.0 mm	599.0 mm	604.0 mm
Q cockpit min. stack	562.0 mm	573.0 mm	586.0 mm	604.0 mm	623.0 mm	643.0 mm	662.0 mm
R crank arm length	165.0 mm	165.0 mm	170.0 mm	170.0 mm	172.5 mm	172.5 mm	175.0 mm
S fork offset	47.0 mm	47.0 mm	47.0 mm	44.0 mm	44.0 mm	44.0 mm	44.0 mm
