Engineered to defy gravity and elevate your performance, the Addict RC is our lightest production race bike ever. Whether you're attacking steep climbs or sprinting for the finish line, every aspect of this bike was meticulously crafted with one thing in mind – leaving everyone else in the dust.

Key features

• Addict RC HMX Carbon frame
• Shimano 105 Di2 24 Speed drivetrain
• Shimano 105 brakes brakes
• Syncros Capital 1.0 40 Disc wheelset
• Continental Grand Prix TR tires, 30x622
• Syncros Carbon & Alloy components
• Syncros handlebar tool

Technical Specifications

Frame	Addict RC HMX, race geometry, replaceable derailleur hanger, internal cable routing
Fork	Addict RC HMX Flatmount Disc, 27.2mm eccentric carbon steerer
Headset	Acros AIF-1317
Rear Derailleur	Shimano 105 Di2 RD-R7150 24 Speed, Electronic Shift System
Front Derailleur	Shimano 105 Di2 FD-R7150, Electronic Shift System
Shifters	Shimano 105 Di2 ST-R7170, 24 Speed Electronic Shift System, Shimano BR-R7170 Hyd.Disc
Brakes	Shimano BR-R7170 Hyd.Disc
Crankset	Shimano 105 FC-R7100, Hollowtech II 52-36T
Front Disc Rotor	Shimano RT-CL700, 160mm
Rear Disc Rotor	Shimano RT-CL700, 140mm
BB-Set	Shimano BB-RS500-PB
Handlebar	Syncros HB-R100-AL
H'stem	Syncros ST-R100-AL
Seatpost	Syncros SP-R101-CF
Seat	Syncros Belcarra V 2.0 Cut-out, CrMo rails
Chain	Shimano CN-M6100
Wheelset	Syncros Capital 1.0 40 Disc, 24 Front, 24 Rear, Syncros Axle
Cassette	Shimano CS-R7100, 11-34
Extras	Syncros handlebar tool, Shimano Built in DN300
Approx weight in KG	7.8
Approx weight in LBS	17.2
Battery	Shimano Built in DN300
Grips	Syncros RC Bartape
Front Tire	Continental Grand Prix TR 30x622
Rear Tire	Continental Grand Prix TR 30x622
Max. System Weight	120kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.



Geometry

	XXS_47	XS_49	S_52	M_54	L_56	XL_58	XXL_61
A head tube angle	71.3 mm	71.8 mm	72.3 mm	72.8 mm	73.4 mm	73.6 mm	73.8 mm
B head tube length	90.0 mm	100.0 mm	113.0 mm	130.0 mm	150.0 mm	170.0 mm	190.0 mm
C top tube horizontal	519.0 mm	528.0 mm	542.0 mm	555.0 mm	572.0 mm	586.0 mm	602.0 mm
D standover height	725.0 mm	740.0 mm	758.0 mm	778.0 mm	799.0 mm	820.0 mm	840.0 mm
E BB offset	-74.0 mm	-74.0 mm	-73.0 mm	-72.0 mm	-72.0 mm	-72.0 mm	-72.0 mm
F BB height	270.5 mm	270.5 mm	271.5 mm	272.5 mm	272.5 mm	272.5 mm	272.5 mm
G wheel base	977.0 mm	983.2 mm	988.8 mm	990.8 mm	999.0 mm	1006.4 mm	1015.4 mm
H BB center to toptube center	412.5 mm	432.5 mm	452.1 mm	472.0 mm	492.2 mm	512.3 mm	532.4 mm
I BB center to top of seattube	422.5 mm	442.5 mm	462.1 mm	482.0 mm	502.2 mm	522.3 mm	542.4 mm
J seat angle	74.5 mm	74.5 mm	74.0 mm	73.6 mm	73.3 mm	72.8 mm	72.5 mm
K chainstay	410.0 mm	410.0 mm	410.0 mm	410.0 mm	410.0 mm	410.0 mm	410.0 mm
L reach	379.4 mm	386.3 mm	391.6 mm	395.2 mm	402.6 mm	406.1 mm	411.3 mm
M stack	501.3 mm	512.5 mm	525.5 mm	543.3 mm	564.5 mm	584.3 mm	604.2 mm
N stem length	80.0 mm	90.0 mm	100.0 mm	110.0 mm	110.0 mm	120.0 mm	120.0 mm
O handlebar width	360.0 mm	380.0 mm	380.0 mm	400.0 mm	400.0 mm	400.0 mm	420.0 mm
P cockpit reach	530.0 mm	547.0 mm	563.0 mm	577.0 mm	585.0 mm	599.0 mm	604.0 mm
Q cockpit min. stack	562.0 mm	573.0 mm	586.0 mm	604.0 mm	623.0 mm	643.0 mm	662.0 mm
R crank arm length	165.0 mm	165.0 mm	170.0 mm	170.0 mm	172.5 mm	172.5 mm	175.0 mm
S fork offset	47.0 mm	47.0 mm	47.0 mm	44.0 mm	44.0 mm	44.0 mm	44.0 mm
