The SCOTT Spark DC 20 is built for riders who want more from every ride. Grounded in our world-class racing pedigree, it brings together cross-country speed and downhill attitude in a single, capable package—engineered for deep mountain missions without compromise.
Every detail is considered to deliver efficiency, stability, and playfulness in equal measure. A low center of mass keeps the ride balanced and controlled through flow trails and jump lines, working through the 140mm front and 135mm rear travel with confidence. The lightweight next-generation HMF carbon frame floats on the climbs and accelerates decisively out of corners and onto open singletrack—a balance of performance and capability refined throughout the Spark legacy.
Keeping your wheels planted—unless that's not your goal—are the ultralight Fox 36SL fork and Float Factory shock, both with a custom tune built for a plush, responsive feel that makes every trail genuinely enjoyable. From short rides and feature sessions to full weekend epics, the suspension is engineered to elevate trail riding across whatever you have planned.
The component spec makes it a high-value package without compromise. Shimano XT Di2 wireless drivetrain and Syncros Silverton AL2 alloy wheels deliver reliable, precise performance across every condition. Integrated frame storage keeps your Save The Day kit and essentials close, and generous bikepacking compatibility means the bike is just as ready for multi-day escapes as it is for your local riding.
Performance also extends to practicality. Improved serviceability and tunability make it straightforward to customize your setup and keep the bike riding exactly how you like it—so you spend less time in the workshop and more time on the trail.
| Frame |
Spark DC HMF Carbon Gen5, Adjustable Head angle and Fork lock, Syncros Cable Integration System Gen2, BSA BB, UDH Interface, 12x148mm with 55mm Chainline
|
| Fork |
Fox 36SL Factory Grip SL, Kashima, 3P, Kabolt 15x110mm axle, tapered Steerer, Reb. Adj, Lockout
|
| Travel |
Front: 140 mm, Rear: 138 mm
|
| Rear Shock |
Fox Float Factory Traction Control EVOL, Kashima, SCOTT custom w. travel, geo adj., 3P: Lockout-Traction Control-Descend, Low Speed & Reb. Adj., Bearing Hardware 20x8mm, 210X50mm
|
| Remote System |
SCOTT TwinLoc Technology, Suspension & Dropper Remote, 3 Suspension modes
|
| Headset |
Syncros - Acros angle adjust +-0.5°, fork lock, stainless bearings, IS52
|
| Rear Derailleur |
Shimano XT Di2 RD-M8250 12-speed, Wireless Electronic Shift System
|
| Shifters |
Shimano Deore Di2 SW-M6250
|
| Brakes |
Shimano Deore BR-M6220 4-Piston
|
| Crankset |
Shimano XT FC-M8200, 32T
|
| Front Disc Rotor |
Shimano RT-CL700, 180mm
|
| Chainguide |
Spark DC Gen5 chainguide
|
| Rear Disc Rotor |
Shimano RT-CL700, 180mm
|
| BB-Set |
Shimano BB-MT501 BSA
|
| Handlebar |
Syncros HB-M200-AL1, Alloy 7075, 760mm, 31.8mm, 7°, 20mm rise, Syncros lock-on grips
|
| H'stem |
Syncros DC ST-M200-AL2, 0°, 31.6mm
|
| Seatpost |
Syncros Dropper Post SP-M301-AL2, +RAD 2.0 drop adjust, 31.6mm
|
| Seat |
Syncros Tofino R 2.0, CrMo Rails
|
| Chain |
Shimano CN-M6100
|
| Wheelset |
Syncros Silverton AL2, CL, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready, 28H, Micro Spline
|
| Cassette |
Shimano Deore CS-M7200, 10-51T
|
| Extras |
Syncros Tool
|
| Accessories |
Milkit Sealant
|
| Approx weight in KG |
12.7 Tubless
|
| Approx weight in LBS |
28 Tubless
|
| Grips |
Syncros XC Lock-On, ready for Tubeless plug Kit Storage
|
| Front Tire |
Maxxis Forekaster 29x2.4", 120TPI Foldable, 3C Maxx Terra, Tubeless Ready, EXO
|
| Rear Tire |
Maxxis Recon 29x2.4", 120TPI Foldable, 3C Maxx Terra, Tubeless Ready, EXO
|
| Max. System Weight |
130kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
|
