Sub Cross 30 is your go-to ride for getting around town with efficiency and in style at an approachable price point. Designed around an alloy frame that prioritizes comfort, stability, and convenience, it’s a dream ride for those looking to tour around or roll a low-hassle commute into the office.
It’s light and nimble in traffic, and planted in the rougher sections on the route with a 63mm suspension fork and wide all-condition Kenda Booster Tires. Shimano’s 9-speed drivetrain gives range to explore and hydraulic brakes give the confidence to handle the unexpected on the ride.
Â
Key Features
- Sub Cross alloy frame
- SR Suntour NEX front fork, 63mm
- Shimano Cues 9 speed drivetrain
- Tektro 2 piston brakes
- Kenda Piedmont tires
- Durable alloy components
- Rear rack, fender and kickstand compatible
-
Frame
Sub Cross, Alloy 6061, custom butted tubing, internal routing, fender and rack compatible
-
Travel
Front travel: 63 mm
-
Fork
SR Suntour NEX
-
Rear Derailleur
Shimano Cues RD-U4000 9-Speed
-
Shifters
Shimano Cues SL-U4000 with Display
-
Crankset
Prowheel C10Y-NW, 36T Steel, Chainguard
-
BB-Set
Feimin FP.B908N, BB73, square taper
-
Chain
Shimano CN-LG500
-
Cassette
Shimano Cues CS-LG300, 9-Speed 11-46T
-
Brakes
Tektro TKD 176, 2-Piston, 160mm Rotor, Hydraulic
-
Grips
Syncros Comfort Lock On grips
-
Handlebar
HL MTB-AL-312BT, Black, 12mm rise
-
H'stem
HL TDS-C342-8FOV, 10°, 31.8, Black
-
Seatpost
HL SP C207, 31.6mm, Black
-
Seat
DDK Vacuum Saddle
-
Headset
Headset ZS44-50mm, 1 1/8"
-
Front Hub
Formula DC-19 FQR Disc, 5x100mm
-
Rear Hub
Formula DC-25 8s RQR Disc, 5x135mm
-
Spokes
Stainless Black
-
Front Rim
Alex Rims X20 Disc 29'' 32H
-
Rear Rim
Alex Rims X20 Disc 29'' 32H
-
Front Tire
Kenda Piedmont 700 x 50
-
Rear Tire
Kenda Piedmont 700 x 50
-
Pedals
Feimin FP-803, w/Reflector
-
Approx weight in KG
13.48 without pedals
-
Approx weight in LBS
29.72 without pedals
-
Max. System Weight
130kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
